Summit Outdoor Built-In Panel Ready Icemaker – 62 Lb Capacity

Have crystal clear ice on-demand whether indoors or outdoors with this built-in capable icemaker from Summit.

This Summit icemaker can make up to 62 pounds in a day while the storage bin can hold up to 26 lbs at a time. It produces gourmet dice-style ice cubes that are perfect for chilling cocktails and drinks and can be easily served with the included scoop. Just plug it in and let it work its magic because it has no-frost operation to keep it running smoothly.

Featuring a sturdy stainless steel cabinet and a weatherproof design, this icemaker can be installed either inside your home bar or it can be used outdoors bars and patios. It measures 15″ wide with an integrated stainless steel frame that works with overplay panel to match your existing cabinetry. (panel size: 29 9/16″ H x 14 7/8″ W at 3/4″ thick) This unit features a front-breathing cooling system and fully finished sides so that it can be used as a freestanding ice maker or it has the capability to be built under counter. This model utilizes a gravity drain system.

The Summit BIM68OSGDRIF is ETL-S listed to NSF-12 commercial standards for use in foodservice settings.

NOTE: This unit requires professional installation. Drain hose and other connection equipment is not included.

• Commercially Approved
• Weatherproof design
• 62 lb. production capacity
• Built-in capable
• Panel-ready door
• Stainless steel wrapped exterior
• Clear ice cube production
• Frost-free operation
• Requires connection to gravity drain
• Factory-reversible door; not field-reversible
• Operates with a standard 1/4” OD water supply line
• Sealed back
• 100% CFC free
• Designed and manufactured in South Korea

• Height of Cabinet 33.5″ (85 cm)
• Height to Hinge Cap 33.63″ (85 cm)
• Width 14.88″ (38 cm)
• Depth 22.63″ (57 cm)
• Depth with door at 90° 37.25″ (95 cm)
• Capacity 0.98 cu.ft. (28 L)
• Defrost Type Frost-Free
• Door Panel-Ready
• Cabinet Stainless Steel
• US Electrical Safety ETL
• Canadian Electrical Safety ETL-C
• Sanitation ETL-S
• Amps 4.0
• Voltage/Frequency 115 V AC/60 Hz
• Weight 105.0 lbs. (48 kg)
• Shipping Weight 110.0 lbs. (50 kg)
• Parts & Labor Warranty 1 Year
• Compressor Warranty 5 Years
• UPC 761101061801
• Icemaker
• Door Swing RHD
• Reversible Factory Reversible
• Daily Ice Production 62.0 lbs. (28 kg)
• Ice Storage Capacity 26.0 lbs. (12 kg)
• Size of Cube 1 1/4″ H x 1 1/8″ W x 1 1/8″ D
• Number of Ice Cube Sizes 1
• Fan Type Exterior
• Refrigerant Type R134a
• Refrigerant Amount 7.4 oz.
• High Side PSI 210.0
• Low Side PSI 102.0
• Interior Height 12.75″ (32 cm)
• Interior Width 12.75″ (32 cm)
• Interior Depth 9.25″ (23 cm)
• Level Legs 4
